22-Frequency GNSS Spoofing Module | Full-Band Anti-Drone Navigation Deception Device

Core Product Technical Parameters

Below are the complete standardized performance, electrical, structural and environmental parameters of the 22-frequency full-band GNSS spoofing module for quick inquiry and project reference:

Product Overview

This device is an industry-leading 22-frequency full-band GNSS spoofing device tailored for high-reliability and scalable counter-drone airspace security operations. Adopting advanced full-band navigation satellite signal simulation technology, the device supports 22 mainstream navigation frequency points covering four major global navigation systems (GPS, BDS, GLONASS, Galileo), as well as mainstream Japanese and Indian navigation signals, achieving comprehensive full-system signal coverage.

It can simulate high-fidelity real satellite navigation signals that are highly consistent with authentic orbital signals, realizing precise and controllable deception intervention on GNSS-dependent UAVs. The device supports multiple core countermeasure functions including drone route diversion, airborne deterrence, forced emergency landing, navigation signal jamming and prohibited takeoff control, enabling safe, non-kinetic and efficient low-altitude airspace management.

Featuring configurable deception distance, flexible trajectory programming, high-precision parameter customization and excellent environmental durability, It supports external command secondary development and multi-device linkage. It is widely applicable to energy facilities, public security defense, large-scale event security, border and confidential unit protection, providing future-oriented and stable full-chain anti-drone security solutions for high-risk scenarios.

Core Functions

• Full-Band Global Navigation Signal Simulation: Supports signal reception, analysis and simulated transmission of GPS, BDS, GLONASS, Galileo and mainstream Japanese & Indian navigation systems, covering 22 mainstream civilian navigation frequency points to adapt to all types of navigation drones on the market.

• Multi-Mode Drone Navigation Deception: Effectively deceives UAVs relying on satellite positioning systems, realizing multiple precise control objectives including forced landing, heading guidance, takeoff prohibition, and navigation signal suppression interference.

• Azimuth Identification & Precise Trajectory Control: Compatible with external direction-finding modules to identify target drone azimuth. It supports precise horizontal control of target UAVs, realizing flexible forward, backward, left and right movement guidance.

• Custom Signal Combination Transmission: Supports external command control for arbitrary matching and transmission of different navigation signal combinations, adapting to diverse drone model countermeasure scenarios.

• Arbitrary Position Coordinate Customization: Allows users to set arbitrary longitude, latitude and altitude positioning coordinates via external commands, and supports built-in fixed coordinate quick calling for flexible scene switching.

• Simulated Motion Parameter Configuration: Supports external custom setting of signal delay, flight motion speed, acceleration and other core simulated parameters to achieve high-simulation dynamic deception.

• Preset & Custom Trajectory Simulation: Supports one-click setting of regular trajectories such as linear motion and circular motion via external commands, and allows importing custom motion trajectories. The module autonomously calculates and outputs matching navigation satellite signals.

• Dual Ephemeris Working Modes: Equipped with real-time ephemeris and permanent ephemeris dual modes, ensuring stable signal simulation and normal deception operation even in signal-shielded environments.

• Navigation Signal Suppression & Jamming: Integrates navigation signal suppression and active interference output functions, realizing dual defense of soft deception and hard jamming.

• Open Secondary Development Interface: Provides standard network secondary development control interfaces and complete protocols, convenient for system integration, equipment linkage and personalized function customization.

Application Scenarios

1. Perimeter Security & Low-Altitude Supervision

Accurately identifies and intercepts low-altitude, slow-speed and small illegal drones within a 1-3km perimeter range. It can force invading drones to land and assist operators in locating and arresting drone controllers. The device supports seamless docking with existing security defense systems to build an intelligent low-altitude supervision defense line.

2. Critical Energy Facility Protection

Suitable for oil & gas stations, power plants and other key energy facilities. It supports 24/7 unattended stable operation, adapting to harsh outdoor weather conditions. It integrates directional and omnidirectional signal interference functions, and automatically records all defense event data to realize traceable safety management of facility low-altitude defense.

3. Large-Scale Event Security

Supports multiple deployment methods including fixed installation, vehicle-mounted deployment and portable handheld use. The device operates silently without noise pollution or on-site disturbance, effectively preventing illegal drone shooting, smuggling and disturbance behaviors, and maintaining on-site public security and order for large-scale activities.

4. Border & Confidential Unit Defense

Comes with strong anti-interference capability, which can effectively resist drone signal camouflage and covert invasion. Adopting encrypted signal transmission and no sensitive data storage design, it fully meets military and confidential security standards. It realizes the closed-loop defense capability of "detection - response - traceability" to protect core confidential information and border security.

Product Advantages

• 22 Full-Frequency Ultra-Wide Coverage: Covers all mainstream global navigation frequency points, compatible with almost all civilian navigation drones, with strong universal adaptability.

• High-Precision Adjustable Performance: 80dB wide-range attenuation adjustment with 1dB ultra-high resolution, matched with 5-50W wide power range and multi-level adjustable deception distance, meeting precise defense needs of different scenarios.

• Dual-Mode Deception & Jamming: Integrates navigation spoofing soft control and signal suppression hard jamming, with dual defense mechanisms and higher interception success rate.

• Strong Environmental Adaptability: IP65 high-level protection and wide temperature working range, stable operation in extreme cold, high temperature, rain and dust environments.

• High Expandability: Open network interface, supporting secondary development, external module docking and multi-device networking linkage, convenient for system upgrade and integrated deployment.

• Safe & Confidential Operation: Encrypted signal transmission, no sensitive data storage, silent and non-radiative operation, suitable for high-level confidential defense scenarios.
