PL 200C Fixed Drone Detection, Jamming & Navigation Deception System

Core Technical Specifications

Below are the complete standardized technical parameters of the PL 200C fixed all-in-one anti-drone system, covering full-band detection, RF jamming, navigation deception, mechanical and environmental indicators for project selection and technical docking:

Product Overview

The PL 200C is a fixed-type all-in-one anti-drone defense system integrated with drone detection, RF jamming, and GNSS navigation deception functions. Developed for illegal low-altitude drone intrusion, malicious reconnaissance, and privacy infringement threats, this professional low-altitude security device provides full-dimensional airspace protection for high-risk key areas.

Equipped with 70MHz~6GHz full-spectrum monitoring capability, the system can automatically scan, identify, locate and track all types of civilian and industrial drones within 10km. Once illegal intrusion is confirmed, it triggers high-power RF jamming and optional navigation deception intervention in seconds, forcing invading drones to hover, return home or perform emergency forced landing. It supports 24/7 unmanned intelligent defense, effectively blocking illegal drones from entering core defense zones and eliminating low-altitude security risks.

Note: The navigation deception function is optional and can be configured on demand according to user project requirements.

Core System Composition

The PL 200C integrated counter-drone system adopts a modular three-in-one architecture, with stable performance and convenient system expansion:

• Full-Band Detection System: Realizes 360° omnidirectional & full-angle drone signal scanning, capturing multi-dimensional flight data and realizing high-precision positioning recognition.

• High-Power RF Jamming System: Covers all mainstream drone flight control & image transmission frequency bands, forming long-distance strong suppression and effective drone expulsion.

• GNSS Navigation Deception System (Optional): Simulates multi-system satellite navigation signals, realizes spatial deception intervention, and controls drone flight trajectory in a stealth manner.

Advanced Product Features

• 70MHz~6GHz Full-Spectrum Coverage: Supports full-frequency scanning and identification, compatible with DJI, Autel, FPV, self-made drones and almost all mainstream UAV models on the market, achieving zero blind spot detection.

• Highly Integrated All-in-One Design: Integrates detection, jamming and deception functions in one system, abandoning fragmented equipment deployment; compact structure saves installation space and reduces deployment costs.

• Powerful FPV Drone Defense: Optimized for FPV high-speed drone and analog image transmission signal suppression, solves the problem of difficult identification and interception of low-altitude FPV invading drones, with outstanding defense effect.

• 24/7 Unmanned Intelligent Operation: Supports automatic identification, early warning, positioning and linkage disposal. The system autonomously activates jamming and deception strategies without manual intervention, realizing round-the-clock intelligent airspace management.

• Strong System Expandability: Reserved expansion interfaces, supporting seamless integration with radar, photoelectric tracking and other security equipment. Adaptable to single-device independent operation and multi-device networking for wide-area airspace defense.

• Built-In Intelligent Signal Learning: Automatically collects, extracts and analyzes unknown drone signals, supplements and updates the local feature library continuously, improving the system’s adaptability to new-type threat drones.

• Military-Grade Durability: Adopts aviation aluminum alloy body, resisting extreme high and low temperature environments, with excellent environmental adaptability and long-term outdoor stable operation capability.

• Customizable Defense Solutions: Supports personalized function configuration and strategy customization according to user scenarios, meeting differentiated defense demands of different security levels.

Cloud Platform Intelligent Management Functions

The supporting high-definition GIS cloud management platform realizes visualized, digital and intelligent whole-process defense management:

• Auto & Manual Dual Control Modes: Automatically completes drone discovery, identification, alarm, positioning and jamming suppression; supports manual intervention for precise disposal.

• Black & White List Management: Effectively distinguishes authorized cooperative drones and illegal invading drones, avoiding false alarms and ensuring normal flight of legal UAVs.

• HD GIS Visual Monitoring: Displays real-time equipment deployment, peripheral airspace environment and drone intrusion tracks on the electronic map for intuitive global monitoring.

• Historical Log Playback & Data Statistics: Automatically records intrusion time, frequency, track and alarm information, supports log playback and automatic generation of airspace threat statistical reports.

• High-Precision Positioning & Automatic North Calibration: Built-in GPS positioning module, supporting map marking and automatic north calibration to ensure accurate defense azimuth.

• Unknown Signal Expansion Library: Realizes automatic collection and manual confirmation of new drone signals, continuously enriching the equipment identification database.

• Real-Time Equipment Status Monitoring: Displays device offline, standby, power-off and abnormal fault status in real time for timely operation and maintenance.

• Diversified Deception Modes: Supports satellite navigation coordinate deception, with linear flight and circular flight simulation modes to realize flexible drone trajectory control.

Application Scenarios

• Key National Security Facilities: Military zones, border defense lines, confidential institutions to prevent drone reconnaissance and infiltration.

• Critical Energy & Industrial Parks: Power stations, oil & gas bases, chemical industrial parks to avoid illegal drone shooting and explosion hazards.

• Large-Scale Public Events: Sports events, conferences and exhibitions to maintain on-site public security and prevent drone disturbance incidents.

• High-Security Residential & Core Areas: Government compounds, VIP activity areas to protect privacy and airspace safety.
