With the rapid development and widespread adoption of drone technology, its applications in aerial photography, agriculture, rescue, and security are becoming increasingly extensive. However, unauthorized intrusion, malicious reconnaissance, and privacy violations are frequent occurrences, posing a serious threat to national security, public safety, and personal privacy. The PL-DT07 fixed drone detection device focuses on precise drone detection and positioning. Through full-band scanning, multi-dimensional information analysis, and alarm functions, it provides front-end perception support for airspace security, meeting the detection needs of scenarios such as daily patrols and protection of important targets.

2. Terms and Abbreviations

Product: PL-DT07 fixed drone detection device.

Supplier: Refers to the seller or manufacturer that provides the equipment.

User: Refers to an individual or organization that purchases equipment and uses it in a related project.

DID (Drone ID): Drone identification protocol used for the transmission and identification of drone identity information.

RID (Remote ID): A drone remote identification protocol used to remotely obtain information such as the drone's location and identity.

FPV (First-Person View): A first-person perspective view, allowing you to view the drone's flight view in real time via image transmission equipment.

GIS (Geographic Information System): A geographic information system used to present geospatial data and environmental information.

3. Product Overview

This product integrates full-frequency detection, drone and pilot positioning, and FPV video capture and storage. It can accurately identify quadcopters, fixed-wing drones, DIY drones, and FPV drones in complex electromagnetic environments, and generate audible, visual, and vibration alarms. It is mainly used in applications such as daily patrols, protection of important targets, squad operations, and investigation and evidence collection.

3.1 Product Name

Fixed Drone Detection Device

3.2 Product Model

PL-DT07

3.3 Product Applications

This product is suitable for scenarios requiring airspace security monitoring, such as airports, government agencies, military restricted areas, large sports venues, and oil and gas fields. It can accurately identify illegally intruding quadcopter, fixed-wing, DIY, and FPV drones, analyze multi-dimensional information about the drone and pilot in real time, and trigger sound, light, and vibration alarms. It provides reliable detection support for daily patrols, protection of important targets, team operations, and investigation and evidence collection, preventing security risks posed by drones.

3.4 Technical Parameters

Serial Number	Name	Performance Indicators
	Detection frequency band	Full-band scanning detection from 70 MHz to 6 GHz (including spectrum analysis function)
	Extended detection band	6GHz-8GHz detection
	Key detection frequency bands	433 MHz, 530 MHz, 750 MHz, 800 MHz, 900 MHz, 1.2 GHz, 1.4 GHz, 2.4 GHz, 3.3 GHz, 5.2 GHz, 5.8 GHz
	Detection range	5km (line-of-sight environment, electromagnetic noise: -90 dB to -95 dB)
	Positioning distance	DID ≥ 5 km, RID≥2 km (suburban line-of-sight environment, electromagnetic environment noise: -90～-95dB);
	Positioning models	Models supporting the DID protocol (O2, O3, O3+, O4, O4+ protocols) and the RID protocol, including all DJI and Autel models and other mainstream drones with RID functionality.
	FPV video transmission detection	≥1.5 km (Supports real-time video viewing, environmental line of sight, analog image transmission power ≥2.5 W)
	Analog video transmission capture	The analog video can be viewed.
	Detection range	The horizontal detection angle can reach 360°
	Detection response time	The time required from powering on the drone to detecting and reporting the drone is ≤5 seconds (under close-range line-of-sight test conditions: the distance between the target drone and the product is ≤500 meters).
	2.4/5GHz direction finding accuracy	≤±15° (RMS, under conditions of no obvious obstructions and no obvious electromagnetic jamming)
	Detection shows	The drone's distance, flight altitude, speed, location (including latitude and longitude, accurate to 1 meter), aircraft model, aircraft serial number (SN), takeoff point, return point, and real-time trajectory are required.
	Cloud platform	(1) It has both unattended and manual control functions, and can automatically complete the detection, identification, alarm, positioning and handling of UAVs. The software automatically starts the jamming product and performs fully automatic tracking and suppression jamming of the UAV based on the UAV location information of the monitored product; (2) It has blacklist and whitelist functions; (3) It has high-definition GIS system functions: it can display information such as the surrounding environment and product deployment points; (4) It has log playback and statistical recording: drone intrusion log, log display angle, alarm time, frequency information, can play back drone intrusion records, and can provide statistical reports on drone intrusion; (5) Positioning function: The system has GPS positioning function and can mark the location on the map; (6) Display the product's offline, standby, power failure and abnormal status; (7) Capable of spoofing with the satellite navigation coordinate information received by UAVs using satellite navigation positioning, with functions such as straight-line mode and circle mode. (Optional function)
	Overall power consumption	≤100 W
	Operating temperature	(-40℃~+60℃) ±2℃
	Weight	≤17 kg
	Dimensions	400 mm * 531 mm (diameter * height)
	Protection level	IP66
	AI learns autonomously to add models to the database.	Optional

4. Product Features and Functions

Full-band detection: 70 MHz to 8 GHz full-band detection

Analysis and positioning: Monitoring multi-dimensional information such as the drone's position (latitude, longitude, azimuth), speed, flight path, and remote controller position (latitude, longitude, azimuth).

FPV video capture: Supports analog image transmission detection from 500 MHz to 6.2 GHz (distance ≥ 1.5 km), can capture and view "first-person perspective" video, and monitor the dynamics of FPV drone intrusion in real time.

Superior detection capabilities: Detection and analysis range up to 5 km

Signal Acquisition (Optional): Comes with drone signal acquisition capabilities, enabling the acquisition and learning of unknown signals.

Multi-scenario adaptation: Supports various usage methods such as fixed and vehicle-mounted, adapting to different application scenarios such as daily patrols and protection of important targets.

5. Product Structure and Components

The product consists of an antenna unit, a radio detection module, a radio positioning and analysis module, a video capture module, a PC terminal, and a main casing.

5.1 Six Views of the Product

5.2 Product List

Serial Number	Name	Picture	Quantity	Dimensions (mm)	Weight (kg)
1	Host		1	400 × 531 (diameter × height)	16.1
2	Cable		2	/	0.3
3	Detection host flight case		1	750 × 520 × 480 (Length × Width × Height)	9.7
4	Tripod and accessories		1	50 × 800 (Diameter × Height)	4.45

6. Product Control and Interfaces

6.1 Product Interface

6.1.1 Detection Head Interface

The detection head is shown below:

Interface Number	Interface Name and Description
1	Power switch button
2	AC input 110 V-240 V
3	Local area network port (LAN port)
4	Wide area network port (WAN port)
5	USB interface
6	Cooling fan
7	5.8 GHz detection antenna
8	2.4 GHz detection antenna

6.2 Product Interface Definition

Module	Power Interface	Data Interface
Detection Equipment	Standard 3-core power cord (Power supply specification: AC220V 50 Hz)	LAN (RJ45), WAN (RJ45), USB data interface

6.3 Product User Interface

Please refer to the software manual for details.

6.4 Product Safety Protection

Packaging dimensions: 750 mm × 520 mm × 480 mm (length × width × height)

7. Product Maintenance and Upkeep

Regularly power on and check the product's status.
