300MHz-6200MHz Wideband Handheld Drone Detector

Technical Parameters

Indicator	Parameter	Notes
Frequency Range	300MHz-6200MHz	Full-band wide coverage
Detection Range	1.5 KM	Standard open environment
Detection Sensitivity	Better than -96dBm	High-precision weak signal capture
Endurance Time	6 Hours	Continuous working
Detection Alarm Mode	Earphone, Sound and Light Alarm	Multi-dimensional early warning
Alarm Logging Capacity	Support no less than 500 alarm records	Support data review
Upgrade & Data Export Interface	Micro USB	Support firmware upgrade & log export
Product Size	135*60*35MM	Ultra-compact body
Product Weight	500 G	Lightweight portable design

Product Overview

The 300MHz-6200MHz Wideband Handheld Drone Detector is a professional portable anti-drone device engineered for full-spectrum low-altitude UAV threat detection. Adopting pure passive detection technology, the device covers an ultra-wide frequency band from 300MHz to 6200MHz, effectively capturing and identifying mainstream consumer drones, industrial drones, analog mapping aircraft and self-assembled UAVs in the market.

Equipped with high-sensitivity signal sensing module up to -96dBm, it achieves long-distance stable detection with a 1.5KM effective detection range. Featuring dual sound-light alarm and earphone alarm modes, 6-hour long endurance, ultra-light 500g body and compact size, this all-in-one detector supports local alarm record storage, data export and firmware upgrade. It is perfectly suitable for site security, event protection, border patrol and various outdoor low-altitude defense scenarios, providing reliable and all-round airspace safety monitoring.

Core Features & Advantages

Full-Band Wide Spectrum Detection
Covers ultra-wide frequency range of 300MHz-6200MHz, compatible with OFDM HD mapping rotary-wing UAVs such as DJI and Daotong, as well as all types of analog mapping traversing aircraft, realizing full-type drone threat coverage without detection blind spots.

High-Precision Weak Signal Capture
Comes with industry-leading detection sensitivity better than -96dBm, which can accurately identify weak drone signals in complex electromagnetic environments, effectively avoid missing or false detection, and ensure monitoring accuracy.

Multi-Mode Intelligent Alarm
Supports three alarm methods including earphone sound alarm, external sound alarm and light alarm. It provides real-time and intuitive early warning reminders, improves on-site situational awareness, and helps security personnel respond to illegal drone threats rapidly.

Long-Endurance Portable Design
Ultra-compact body size of 135*60*35MM and lightweight weight of only 500g, easy to hold and carry for long-time mobile patrol. Built-in high-capacity battery supports up to 6 hours of continuous uninterrupted operation, adapting to all-day field mission needs.

Independent Data Logging & Export
Built-in local storage module, capable of storing no less than 500 groups of alarm records. Supports one-click data export via Micro USB interface, facilitating subsequent data analysis, threat traceability and work report sorting.

Customizable Detection Library
Users can independently add, delete and modify UAV feature libraries through the USB interface, realizing personalized customized detection rules, which can adapt to new types of drone threats and different scenario monitoring demands.

Global Multi-Language Support
Built-in multi-language system including Chinese, English and Russian, meeting the operation habits of global users and perfectly adapting to international security project deployment.

Complete Product Functions

1. Full-Band Passive Detection
Adopts pure passive signal receiving technology without electromagnetic radiation interference. It accurately identifies mainstream brand drones with OFDM high-definition mapping and various analog mapping traversing aircraft within the full frequency band, realizing comprehensive monitoring of low-altitude flight threats.

2. Multi-Dimensional Alarm Reminder
Integrates earphone private sound alarm, external loud sound alarm and flash light alarm. It supports silent covert early warning and on-site obvious reminder modes, meeting the early warning needs of covert patrol and open security scenarios respectively.

3. Automatic Alarm Logging
Automatically records all detected illegal drone events, including detection time, frequency band and equipment characteristics. The device can store more than 500 alarm records locally to ensure complete retention of monitoring data.

4. USB Data Export & Firmware Upgrade
Equipped with universal Micro USB interface, supporting one-click export of historical alarm data for offline analysis and archiving. It also supports online firmware upgrade to continuously optimize detection algorithms and adapt to emerging drone models.

5. Diversified Working Modes
Presets three working modes: default full-band detection mode, key band targeted scanning mode and user-defined feature library scanning mode. Users can switch freely according to on-site environment to improve detection efficiency and pertinence.

6. Custom Feature Library Management
Open user-defined authority of drone feature library. Users can independently update and adjust the detection feature database through USB connection, quickly adapt to new drone types and regional common threat characteristics, and enhance device scenario adaptability.

7. Real-Time Working Status Display
The device screen intuitively displays real-time working status including system language and remaining power, allowing users to grasp device operating conditions at any time and avoid mission interruption caused by power shortage or setting errors.

8. Global Multi-Language Switching
Supports Chinese, English and Russian language switching, with simple and intuitive operation interface, reducing operation barriers for overseas users and realizing convenient global deployment.
